5th gen 4runner Cb radio help

[Señor_Godric]

Hey guys I just bought my 2016 4runner trail edition. I need some help and information about CB RADIOS and installation. I want an affordable build. Can you guys plz help.:bump::frisky::drum:



[Salvo Jimmy]

start here.

http://www.toyota-4runner.org/5th-gen-t4rs/232156-basic-cb-radio-questions.html

search and you will find others



[gm350reratliff]

I run this CB, Midland 75-822 40 Channel CB-Way Radio https://www.amazon.com/dp/B00000K2YR/ref=cm_sw_r_cp_tai_LfgQyb2SRK51E

With this antenna, WILSON 305-38 300-Watt Little Wil Magnet Mount Antenna https://www.amazon.com/dp/B001AAT94W/ref=cm_sw_r_cp_tai_KigQyb5TTBC0D

I keep the cb radio in the glove box until I need it with the only thing left visible inside is the black plastic mic holder on the dash. I did have to extend the coax by about 5 feet but it's easy to do. This setup tuned really good and works good as well.

That being said, we will probably switch to a HAM setup down the road but I need to study up on what I want first.



[Jhalko]

Hey guys I just bought my 2016 4runner trail edition. I need some help and information about CB RADIOS and installation. I want an affordable build. Can you guys plz help.:bump::frisky::drum:

Congrats on the new ride. IMHO, the best bang for your buck, and install that deoesnt require alot of cutting would be something like the cobra 75wxt. Get a mag mount antenna, or if you want more permanent get a Rago ditch bracket and attach the antenna to that. I started with that cb and used a couple write ups here, worked great on the trail. Not much need for more really, I upgraded to a really nice bearcat with SSB but even though it wasn't much more I don't think it was worth it.

If I was doing it again I'd probably get a hand held cb and a permanent Ham install.

Edit for a link:
http://www.toyota-4runner.org/5th-gen-t4rs/94578-okkis-build-thread-2.html#post1028182



[acolle]

I run this CB, Midland 75-822 40 Channel CB-Way Radio https://www.amazon.com/dp/B00000K2YR/ref=cm_sw_r_cp_tai_LfgQyb2SRK51E

With this antenna, WILSON 305-38 300-Watt Little Wil Magnet Mount Antenna https://www.amazon.com/dp/B001AAT94W/ref=cm_sw_r_cp_tai_KigQyb5TTBC0D

I keep the cb radio in the glove box until I need it with the only thing left visible inside is the black plastic mic holder on the dash. I did have to extend the coax by about 5 feet but it's easy to do. This setup tuned really good and works good as well.

That being said, we will probably switch to a HAM setup down the road but I need to study up on what I want first.

I had terrible luck with my Midland 75-822 + Little Wil. Just installed a firestik... Huge improvement!



[e60ral]

Midland 75-822 or Cobra 75WXST
NMO Lip Mount
NMO CB Antenna
NMO Rain cap so you can go through car washes or get into low parking garage
and don't forget a CB antenna SWR meter to tune your antenna

After tuning I'm running about 1.25 SWR with this setup



[Salvo Jimmy]

I had terrible luck with my Midland 75-822 + Little Wil. Just installed a firestik... Huge improvement!

I have the Midland 75-822 with a Wilson 5000 magnetic antenna. SWR at 1.1. The set was tweeked by my truck stop CB shack to make sure it was putting out max legal watts. Out of the box it was down nearly 1 watt.

Works just fine. No it ain't a Cobra 29 but for me with hearing aids and considering the fidelity of CB plus road noise, having the ability to put the speaker near my ear(s) where an aid is located is far better than my 29 with the speaker well away from my aid(s).



[(none)]

Going through this right now. No room in this thing to mount my Cobra 29 as i had it in my JK. Purchased the 75 whatever to see how it does. looks like it'll install pretty easily.

I did purchase a set of CBI ditch light mounts, as a set (which has free shipping) is the same price as 1 (their antennae mount) with shipping. If you want a drivers side mount, let me know. Otherwise i'll just sell it when teh pair comes in.



[Señor_Godric]

I had terrible luck with my Midland 75-822 + Little Wil. Just installed a firestik... Huge improvement!

Hey brotha I'm trying to go with firefly antenna how is it?? What's the best size 3' or 4' :zoom: what's better ham radio like the truckers or the Midland ones



[Señor_Godric]

I run this CB, Midland 75-822 40 Channel CB-Way Radio https://www.amazon.com/dp/B00000K2YR/ref=cm_sw_r_cp_tai_LfgQyb2SRK51E

With this antenna, WILSON 305-38 300-Watt Little Wil Magnet Mount Antenna https://www.amazon.com/dp/B001AAT94W/ref=cm_sw_r_cp_tai_KigQyb5TTBC0D

I keep the cb radio in the glove box until I need it with the only thing left visible inside is the black plastic mic holder on the dash. I did have to extend the coax by about 5 feet but it's easy to do. This setup tuned really good and works good as well.

That being said, we will probably switch to a HAM setup down the road but I need to study up on what I want first.

Thanks for the info. What's the different from HAM radios to the Wilson one you were mentioning? Is the HAM radios the one truckers use? I'm such a greenhorn lol



[Señor_Godric]

Going through this right now. No room in this thing to mount my Cobra 29 as i had it in my JK. Purchased the 75 whatever to see how it does. looks like it'll install pretty easily.

I did purchase a set of CBI ditch light mounts, as a set (which has free shipping) is the same price as 1 (their antennae mount) with shipping. If you want a drivers side mount, let me know. Otherwise i'll just sell it when teh pair comes in.

Got any pictures of installation?



[TravelWest01]

Ham radio is on different bands than CB. Ham also allows you to transmit at higher powers than CB. Downside to Ham is you need to take an exam and get a license, but the exam is easy. Other option is race radio, which are commercial radios used by off-road racers and widely adopted by off-road drivers in general.



[e60ral]

if you dont want CB, and don't want Ham, just get some FRS/GMRS bubble pack radios, the quality and range is plenty fine for convoy and trail rides



[brian0128]

I run this CB, Midland 75-822 40 Channel CB-Way Radio https://www.amazon.com/dp/B00000K2YR/ref=cm_sw_r_cp_tai_LfgQyb2SRK51E



With this antenna, WILSON 305-38 300-Watt Little Wil Magnet Mount Antenna https://www.amazon.com/dp/B001AAT94W/ref=cm_sw_r_cp_tai_KigQyb5TTBC0D



I keep the cb radio in the glove box until I need it with the only thing left visible inside is the black plastic mic holder on the dash. I did have to extend the coax by about 5 feet but it's easy to do. This setup tuned really good and works good as well.



That being said, we will probably switch to a HAM setup down the road but I need to study up on what I want first.

Where did you run the coax to the outside of the vehicle?



[(none)]

Got any pictures of installation?

I will once i get it in :tongue:



[gm350reratliff]

Where did you run the coax to the outside of the vehicle?

I ran the coax through the taillight housing area then up to the rear of the cargo rack. I think there's some pics in the build thread.



[brian0128]

Midland 75-822 or Cobra 75WXST
NMO Lip Mount
NMO CB Antenna
NMO Rain cap so you can go through car washes or get into low parking garage
and don't forget a CB antenna SWR meter to tune your antenna

After tuning I'm running about 1.25 SWR with this setup

Where did you mount the lip mount? Any pictures of install?



[e60ral]

Sent from my P00A using Tapatalk



[Salvo Jimmy]

Something to consider when mounting an antenna is what your antenna pattern looks like.



[Motoman_TRD]

Sent from my P00A using Tapatalk

That's a nice fit in the dash!!
