5th Gen Engine Air Filter Question

[fenderltd]

I bought this Filter off ebay and noticed it was a hair different. The part # of the my original is 17801-38051 new part # 17801-yzz13


The Toyota dealer I bought it from says Toyota quit making the 38051 and this is new updated part #. It's the same of everything except the charcoal filter thing isn't present. I can still get the same exact old one if need be, just curious if anyone has ran into this same problem.



[<<<<]

Yep, that is what you get when order one in North America. It works fine. I get Charcoal type from local dealer.



[Bbqqin]

Yep, that is what you get when order one in North America. It works fine. I get Charcoal type from local dealer.

+1 for different when you order from NA.



[fenderltd]

Do you think you get better mileage without the charcoal filter? lol



[DavidR1]

I just ordered one off Amazon, part number 17801-38051 was delivered. Maybe they are moving through old stock?



[fenderltd]

I just ordered one off Amazon, part number 17801-38051 was delivered. Maybe they are moving through old stories ck?

Not sure, I like the one with the charcoal filter thing so I'm going to buy like 5 of them to have them.



[TOYO74]

Can those of you who refer to the engine air filter "with charcoal" explain to me what this does for the engine?

I know some CABIN air filters use charcoal impregnated material to absorb odors from the air entering the cabin or the cabin air itself when the blower is set to recirculate.

Why would this be needed for an ENGINE air filter? I thought the main purpose of the ENGINE air filter was to remove intake air particulates, not to remove odors from the intake air. Am I wrong?



[green_manalishi]

Can those of you who refer to the engine air filter "with charcoal" explain to me what this does for the engine?



I know some CABIN air filters use charcoal impregnated material to absorb odors from the air entering the cabin or the cabin air itself when the blower is set to recirculate.



Why would this be needed for an ENGINE air filter? I thought the main purpose of the ENGINE air filter was to remove intake air particulates, not to remove odors from the intake air. Am I wrong?

I assume it's the same function as the non-removable filter on the gen 4. Keeps volatile organic fumes from escaping the intake after the engine has been turned off. Emissions stuff.


Sent from my iPhone using Tapatalk



[TOYO74]

I assume it's the same function as the non-removable filter on the gen 4. Keeps volatile organic fumes from escaping the intake after the engine has been turned off. Emissions stuff.


Sent from my iPhone using Tapatalk

I believe that is a charcoal canister which is part of the emission control system and is a completely different and separate system....It has nothing to do with the air filter for the engine air intake.

Engine air intake filter does one thing==filter particulates from air entering the air intake.



[green_manalishi]

I believe that is a charcoal canister which is part of the emission control system and is a completely different and separate system....It has nothing to do with the air filter for the engine air intake.

Engine air intake filter does one thing==filter particulates from air entering the air intake.

I'm not talking about the evap. system; I'm referring to the permanent charcoal filter which sits directly above the air filter. It's a 4th gen thing, but seems to serve the same function as the filter described in this thread.

It's interesting that they discontinued this filter for the 5th gens. I wonder if the emission regulations changed?



[TOYO74]

I'm not talking about the evap. system; I'm referring to the permanent charcoal filter which sits directly above the air filter. It's a 4th gen thing, but seems to serve the same function as the filter described in this thread.

It's interesting that they discontinued this filter for the 5th gens. I wonder if the emission regulations changed?

Thank you for the link! I like how they removed the charcoal part to improve air flow... some design Emissions Control engineer probably had a heart attack if they saw that thread.

Also, thanks for your patience explaining this thing. I went from a 1st gen 4Runner that I drove for 32 years to a 5th gen in 2016 so I missed several generations of changes!

Thanks again!



[green_manalishi]

Thank you for the link! I like how they removed the charcoal part to improve air flow... some design Emissions Control engineer probably had a heart attack if they saw that thread.

Also, thanks for your patience explaining this thing. I went from a 1st gen 4Runner that I drove for 32 years to a 5th gen in 2016 so I missed several generations of changes!

Thanks again!

Hey, that's what we're all here for. Learning.



[Fidgets]

Amazon still sells 38051.

I've never seen an engine air filter with carbon, just white pre-filters for cold climes. Learn something new every day.



[Pgshields]

How often do you guys change yours out? Express tells me every time I need a new one haha



[(none)]

How often do you guys change yours out? Express tells me every time I need a new one haha

I think the manual recommends every 20k miles. Would be more frequent in dirty/dusty environments.


I think the 5th gens have that extra filter/ screen in the stock airbox. I'd have to check, but I thought I remember seeing it while doing the TRD airbox swap. The TRD airbox has a more open screen I believe.



[Dalko43]

Is there any danger with using a filter without the charcoal/white prefilter?

I just installed a new filter in the airbox and I noticed that it didn't have white cloth on the bottom side that my old one did.



[(none)]

the white stuff on the filter itself is a snow filter. No need to really worry about it.



[BrianR383]

the white stuff on the filter itself is a snow filter. No need to really worry about it.

Where did you find this info? I have always wondered what the deal with the foam prefilter was, but I haven't been able to find much info. This is my first vehicle that has that.



[oljedi11950]

Afe pro dry & never look back !



[tqlspec]

difference between filters

I work for the company that makes both filters. The -38051 is made at a plant in Japan and the -YZZ13 is made in the U.S.

They both have the same design - the only difference is the pre-filter. The -38051 will hold more dust. The pre-filter is primarily for vehicles used in the mid-east (Saudi Arabia, etc.). So Toyota ships all vehicles with the -YZZ13. The pre-filter is not needed in the U.S. unless you do a lot of desert driving. And, you would have to do a lot of desert driving to actually need it.

Some dealers apparently choose to only carry the -YZZ13 version, but it is available online. I can't speak for why some dealers don't carry both versions. The -YZZ13 usually has a smaller price tag since it's missing the pre-filter.

The pre-filter is white when it ships in a new vehicle and turns dark after use. There is no charcoal in the pre-filter.
