Internal snorkel mod

[aha2988]

Just a write up on how to make a cheap working snorkel i know theres alot of threads already on this but i couldnt find any threads with working pictures so I'm throwin it out there for anyone interested.

http://www.toyota-4runner.org/off-roading-home-monst4rs/113733-internal-snorkel-mod-4th-gen.html



[BlackWorksInc]

How is it "Internal?" It just looks like the pipe feeds into the body, how high is the inlet?



[T4runner13]

It looks like it is pulling air from inside the cab....internal?



[SkylineGTRracer]

2006 Wk Jeep Grand Cherokee Dual Snorkle Fabrication WATERPROOF! - YouTube



[BlackWorksInc]

I wonder if we have enough room in our A-Pillars to run a snorkel through them... I wouldn't mind a way to have a sleek or hidden looking snorkel.



[aha2988]

It's pulling air from inside the cab just behind the ECU. Its internal because it sits between the outer fender and the inner fender. once installed the snorkel can't be seen or heard from outside the vehicle. Only evidence of the Modification is some sylicone trails inside the air box and the awesome sounds your engine makes coming through your intake into the cab. durring normal daily driving you can barly hear the air flow but once you get on it you can really hear your motor open up sounds awesome get tired of hearing it just turn your radio on an its covered right up. heres some finished wraped up pics. there from the phone so qaulity sucks but as you can see sleek and hidden
