Lighting Diagram

E

EPatt

New member
Anyone have an interior diagram of a first gen?

I have an 87 and the lighting sucks. Looking to upgrade it all to LED.

Just wondering if anyone had a chart with locations and bulb sizes. I had one for my 3rd gen but that won't help me now

Register to hide this ad
EPatt said:
I have an 87 and the lighting sucks. Looking to upgrade it all to LED.
Click to expand...

Really? ALL? Why not start with the unsafe, dim, yellow headlights and the circuit that subjects the dimmer-combo switch to high currents? Search:
"H4 Conversion harness" (essential to do first), then "Headlight housing upgrade", OR "Trucklites"! :)
Trucklite_Order_zpsiklzqwbi.png~original

RAD4Runner said:
Really? ALL? Why not start with the unsafe, dim, yellow headlights and the circuit that subjects the dimmer-combo switch to high currents? Search:

"H4 Conversion harness" (essential to do first), then "Headlight housing upgrade", OR "Trucklites"! :)

Trucklite_Order_zpsiklzqwbi.png~original
Click to expand...


Why? Bc it's a trail truck and driven 99% on the trails. 2 LEDs and a lightbar handle the majority of my outside lighting if/when I need it

Last edited:
Bad_Vision said:
It's 12v lighting just put brighter bulbs and more of them.
Click to expand...


I understand that. Just looking to see which bulbs are where. I know the cluster has 3 194 bulbs in it. Just wondering if there was a list somewhere that had all the bulbs before I tear the interior apart and have to find them on my own.

Would like to have them all ordered and in hand so I only have to tear it apart once

EPatt said:
I understand that. Just looking to see which bulbs are where. I know the cluster has 3 194 bulbs in it. Just wondering if there was a list somewhere that had all the bulbs before I tear the interior apart and have to find them on my own.

Would like to have them all ordered and in hand so I only have to tear it apart once
Click to expand...

FOund it. Owner's Manual...
20160215_113826_zpsd2zf4dqa.jpg~original

Any info on gauge and dash? I know there are 3 194's in the gauges and 2 in the inclinometer. My bulbs in the AC etc haven't made it the 30 years like the others did
