SENSOR, KNOCK and intake manifold re-man
I started getting P03303 bank 2 sensor 2 codes. it was time to replace the wire harness and knock sensors.
after tearing it down of course I found all kinds of things that needed attention.
here is the parts list for the things I decided to tackle... I will try to fill in pictures as I get parts and re-work things. its going to take a bit.
This site has some great breakdown on parts... the hard to find part numbers can be had here.
https://partsouq.com/en/catalog/genuine/vehicle?c=Toyota&ssd=%24HQwdckgWXEYRDhQ9LDcQHxZcQREOFCExSnp9DAJga20GWV1KBQsDFx4RV1VJX1sEBAUBBAMWGkkIGhAJFmNofQUOXilUdXhkb3lyFhpJAxBWEQ4MHhFCVUlfF0dfWEhMbHRmMicvZGliBgFdABc%24&vid=0&q=JT3HN87RXY0283787
ripped down and waiting for parts
<a href="https://imgur.com/vbcukCd"><img src="https://i.imgur.com/vbcukCdl.jpg" title="source: imgur.com" /></a>
INTAKE MANIFOLD
1717762060 GASKET, INTAKE MANIFOLD TO HEAD, NO.1
4@ 9462310800 WASHER PLATE
4@ 9017908117 NUT
4@ 9014880002 BOLT
4@ 9011908609 BOLT
Lower Plenum AKA AIR SURGE
4@ 9017908183 NUT
4@ 9014980022 BOLT
1@ 9010508020 BOLT(longer bolt)
2@ 1717662040 GASKET, AIR SURGE TANK TO INTAKE MANIFOLD
already on order(verify)
1@ 8221934020 therm sensor wire harness
2@ 8961512050 SENSOR, KNOCK CONTROL Denso
1@ 8342016020 GAGE ASSY, WATER TEMPERATURE SENDER
(Rear of manifold, single wire) part of manifold?
1@ SENSOR WIRE 82219-34020(front ECT wire harness)
1@ SENSOR, WATER TEMPERATURE 89422-35010
(For E.F.I. 2 wires front of manifold)
FUEL INJECTION SYSTEM
12@ 9030107024 RING, O(FOR FUEL DELIVARY PIPE) top n bottom
6@ 2329120010 INSULATOR, INJECTOR VIBRATION (holds injector in manifold)
1@ 2380162070 PIPE SUB-ASSY, FUEL, NO.1
(high pressure supply)
1@ 9040112036 Bolt, Union(For Fuel Pipe NO.2)
1@ 9043012026 BOLT, UNION(FOR FUEL PIPE NO.2) this is really the copper crush
1@ 9030107024 RING, O(FOR FUEL DELIVARY PIPE)
(this is for the REGULATOR ASSY, FUEL PRESSURE connection)
1@ 23273-62020 Hose, Fuel(For Return Hose)
2@ 9613541100 CLAMP OR CLIP(For Return Hose)
1@ 23812-62041 PIPE, FUEL Pipe, Fuel, NO.2(For Return Hose) hard line
1@ 23273-62010 HOSE, FUEL(For Fuel Pipe To Pressure Regulator)
2@ 9046711065 Clip, Hose(For Fuel Hose)
THROTTLE BODY
1@ 22215-62180 GASKET, THROTTLE BODY COVER
2@ 9017908183 Impact Bar Nut
2@ 9011608159 BOLT, STUD
4@ 21821-25180 Screw (for throttle body cover)
2@ 9010508267 BOLT, WASHER BASED
VACUUM PIPING
1@ 1734362080 HOSE, AIR, NO.3
(rear top of manifold driver side)
1@ 1734262080 HOSE, AIR, NO.2
(rear top of manifold passenger side)
1@ 9090413015 WAY, 3(FOR AIR HOSE)
(joins HOSE, AIR, NO.3 <-> HOSE, AIR, NO.2)
1@ 1734162060 HOSE, AIR, NO.1
(joins to throttle body and one way check for super charger)
RADIATOR & WATER OUTLET
3@ 9011606127 BOLT, STUD
1@ 16341-62040 GASKET, WATER OUTLET
3@ 90179-06080 NUT
1@ 16261-62060 HOSE, WATER BY-PASS (water bypass to throttle body front)
2@ 96135-41300 Clamp Or Clip(For Water By-Pass Hose NO.3)
1@ 99556-10300 HOSE, WATER BY-PASS Hose, Heater Water, Outlet C
(water bypass to throttle body rear)
2@ 96135-41300 Clamp Or Clip(For Heater Water, Outlet C)
HEATING & AIR CONDITIONING - WATER PIPING
1@ 8724535700 HOSE, HEATER WATER, OUTLET E (up from water bypass pipe on manifold or HEATER WATER HOSE, NO.2)
1@ 90467-23009 CLAMP OR CLIP ( lowwer )
1@ 9613442100 CLAMP OR CLIP ( upper )
1@ 8726535340 CONNECTOR, HEATER WATER HOSE, NO.2 (3 way )
1@ 872453D090 HOSE, HEATER WATER, OUTLET C
2@ 9046714029 CLIP
1@ 8724535710 HOSE, HEATER WATER, OUTLET A
(not sure what clamp... parts diag is confusing here)
2@ 9613442100 CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2)
2@ 9046722004 CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2)
1@ 87124-35010 CLAMP, HEATER
1@ 9048001405 GROMMET (FOR HEATER PIPE)
1@ 8724535680 HOSE, HEATER WATER, INLET
1@ 9046723009 CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2) (lower)
1@ 9613442100 CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2 (upper)
1@ 8726589110 CONNECTOR, HEATER WATER HOSE (3 way)
1@ 8724535690 HOSE, HEATER WATER, INLET A
2@ 9046722004 CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2)
1@ 8724035070 VALVE ASSY, HEATER WATER
1@ 8724535670 HOSE, HEATER WATER ,INLET C
1@ 9613442100 CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2)
1@ 9046722004 CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2)
1@ 8724535770 HOSE, REAR HEATER WATER INLET, A(FROM ENGINE)
1@ 9046714029 CLIP
