Auxilary Lighting Install Woes

[jaybird93000]

So I've got everything to finish the wiring from my 4 PIAA to the FJ switches. Just really struggling with how it will all go in with there being 2 switches and 2 harnesses. The singular green and purple are connected to the 2 PIAA relays. I've included pictures to maybe help explain what all i'm talking about.

The factory harness pre-installed on the 4runner.

The two wires connected to the 2 PIAA Relays.

FJ Wiring Harness (Switch End)

FJ Wiring Harness (back end)



[zstampe]

Ask MOMO or Gaterose to help you!!!!

Ha ha

:cheers::snacker:



[darkie3495]

Here is a diagram that I made for another member (hopefully this helps):



[honda_nos]

I installed this into an FJ but I didn't use the connection into the kick panel area. I used the light kit's harness for that and only used it as a pigtail for the light switch.

The reasoning for me was that my buddy wanted it wired to a parking light input (+ switch) and also have them on with his high beams.



[sigepbiker]

Kevin, that is a great diagram! I will definitely come back to this post to wire my lights.
