Photo Timeline of my 4Runner {LOTS OF PICS}

[KidVermicious]

Whoa, missed that part. Bryan, this is a stock top shift case off a 1985, 22RE/w56, 21 spline. Does that change the flavor of the koolaid?

Also, it's 70 pounds on my bathroom scale and that's before I build a cradle to ship it in or put it in a tote. It ain't gonna be cheap.



[LINY4Runner]

Whoa, missed that part. Bryan, this is a stock top shift case off a 1985, 22RE/w56, 21 spline. Does that change the flavor of the koolaid?

Also, it's 70 pounds on my bathroom scale and that's before I build a cradle to ship it in or put it in a tote. It ain't gonna be cheap.

Bahh 21-spline isn't gonna work...my coupler is 23-23



[downpour11]

Where you at with your build? Were you able to get the tcase in today?

I think we're still neck and neck with our builds lol :lookout:



[4Running Daily]

At this rate [MENTION=47554]t4r4life[/MENTION] will be done before you guys.



[downpour11]

Well Eric better hurry up cuz I'm almost done lol



[t4r4life]



[KidVermicious]

Bahh 21-spline isn't gonna work...my coupler is 23-23

Sorry to have gotten your hopes up. I was already surfing the Low Range sale trying to decide where I was going to put your money.



[LINY4Runner]

Sorry to have gotten your hopes up. I was already surfing the Low Range sale trying to decide where I was going to put your money.

haha it's cool...not the first letdown of the build and won't be the last I'm sure. Back to the original plan...
[MENTION=56044]downpour11[/MENTION] I didn't get the t-case in yesterday, I decided to spend the day on the bike rather than under the truck lol



[LINY4Runner]

Minor updates with no pictures...got the steering box solidified, steering shaft is in, column and interior is back together and the old transfer case out. Gotta figure out the clocking of the new one and get the adapter on it and zip it in- probably in the next few days...

:guitar3:



[crazydubman]

Pictures or not, progress is progress right? :bigok:

Looking forward to seeing it all buttoned back up. I still need to get your front diff installed.....



[ADH8796]

Minor updates with no pictures...got the steering box solidified, steering shaft is in, column and interior is back together and the old transfer case out. Gotta figure out the clocking of the new one and get the adapter on it and zip it in- probably in the next few days...

:guitar3:

What steering shaft did you use?



[LINY4Runner]

Thanks guys! You know me...pictures are coming!

What steering shaft did you use?

I have the All-Pro steering kit with IFS steering box, frame plates, hardware, telescoping shaft and 2 universal joints



[downpour11]

Hurry up hurry up hurry up hurry up

Let me know when you get to your panhard in and how you mounted everything and fitment. Mine was quite interesting....

How much do you have left on your build?



[LINY4Runner]

Hurry up hurry up hurry up hurry up

Let me know when you get to your panhard in and how you mounted everything and fitment. Mine was quite interesting....

How much do you have left on your build?

Panhard is gonna be interesting for sure. We decided to go with 1-ton steering to go underneath the HiSteer knuckles to make more room up top for up-travel and more space for the panhard.

Left to do:
Install T-Case with adapter and crossmember
Mock, tack, cycle, weld link mounts
Panhard
Cut and weld new steering
Driveshafts
PS lines
Brake Lines (steel lines to go to the marlin braided lines)
Bleed
Drive
Flex on something big
Repair what I just broke flexing on something big
Drive some more
Change some things I didn't like
Drive some more
Wheel
Decide I want IFS
Cut it all out and weld the old stuff back in


lol okay so maybe those last two are a joke...



[LINY4Runner]

I wish I had more free time like [MENTION=56044]downpour11[/MENTION]...

Transfer case is finally in but still not permanently because I'm STILL waiting on the top shift kit from inchworm...this is starting to get ridiculous now...
But the adapter is clocked and drilled and bolted and installed along with the case and the FROR crossmember. Now Dan can get the link mounts in and do some cycling of the suspension and such. 1-ton steering kit is on order. Need the exhaust done because right now it's open at the crossover pipe. Gonna go 2.25" stainless tube from there back, no cats (spark plug non-fouler mod so no P0420), to the good ol' Borla XR-1 that we all know and love. Power steering lines have been sent out and should be back in a few days.

Hmm what else...

Got a wheeling trip coming up in two weeks but I doubt she'll be ready for it...so I'll be designated spotter/filmmaker for that one. Another trip mid-October that I should have my truck for so we'll have to wait till then for action shots.

I think that's all the news I have...

More of a bump than an update...

Because [MENTION=56044]downpour11[/MENTION] is beating me and its making me sad...

so I want attention...

don't forget about me :wave:



[downpour11]

You'd be so close if you had that topshift kit!

And if you had all your parts when you started the build! That's why a lot of these take so long.. always waiting on parts.

Your truck is gonna be sweet though!!



[steezemcqueen]

Keep the cat....



[Dous]

Keep the cat....

I agree, you may need to ditch the gigantic stock one, but they make really small cats that work just the same



[LINY4Runner]

You'd be so close if you had that topshift kit!

And if you had all your parts when you started the build! That's why a lot of these take so long.. always waiting on parts.

Your truck is gonna be sweet though!!

I did have all the parts I thought I needed, but transfer case plans changed :crybaby:

Keep the cat....

I agree, you may need to ditch the gigantic stock one, but they make really small cats that work just the same

You guys think I'll have back pressure issues without it?



[LINY4Runner]

Link mounts are burned to the frame! Wahoooo

Now the links can get mocked up, cycled and welded.

Got my commission check a week early so I ordered the 1-ton steering today.

Still no pics because he's been working without me lately...soon...










soon.
