What the fudge?

[tucktuck8]

So I installed a USB charger into the blank of my center console. I used a positive (pink/blue) wire from an unused plug in by the DAC harness. I confirmed it has power with a light pen thing (don't know what it's called). Then I grounded it to a black ground from my light bar switch (confirmed it was a working ground).

When I turn the ignition to acc or on the charger doesn't work regardless of headlights being on or off. When I turn the car off and remove the key with the headlights on the charger works.

This doesn't make any sense to me! help.



[Speedy Gomez]



[4RunAmok]

First, using a 12 volt Test Light on a vehicle equipped with Can Bus is very dangerous. You could very easily damage a control unit.

Go to Harbor Freight and pick up an affordable, decent multimeter.

Second, go to a known good 12 volt source, like the cigarette adapter, and T-tap into it's power AND ground, avoid choosing alternate grounds to prevent ground loops.

By using the power outlet, you are selecting a source that is already properly fused, and if something goes wrong, it's easier to track down.



[cpark_12]

Second, go to a known good 12 volt source, like the cigarette adapter, and T-tap into it's power AND ground, avoid choosing alternate grounds to prevent ground loops.

By using the power outlet, you are selecting a source that is already properly fused, and if something goes wrong, it's easier to track down.

This! I added 2 usb outlets in my ash tray and spliced into the cigarette lighter that was already there. Everything works as it should.



[tucktuck8]

Alright I will try that. Thank you



[tucktuck8]

Anyone know exactly which wire from the smoker kit plug is the ground??



[BlackWorksInc]

Typical Toyota grounds are Black wires, White with a Black Stripe, and Brown.



[tucktuck8]

Figured it out... If you ever buy.THIS unit just know there is a possibility that the black wire is positive and the red wire is negative.

Isn't red-positive/black-negative pretty universal?

Had me stumped for an hour or so. F&#kers...



Light bar switch looks a little out of place...



[nicholassballs]

Whoah, that is odd. Can you just swap the wires on the back o fthe switch?



[tucktuck8]

Whoah, that is odd. Can you just swap the wires on the back o fthe switch?

The wires on the switch are incased in the housing so there is no way of switching them around :/.

I was about to give up after I tried every wire I could under there.. a lot of cut 3 way splices under there now.



[4RunAmok]

a lot of cut 3 way splices under there now.

Please don't post photos of that, I don't think my wiring OCD could bear it!



[97BlackAckCL]

Please don't post photos of that, I don't think my wiring OCD could bear it!

ditto



[bamma]

Figured it out... If you ever buy.THIS unit just know there is a possibility that the black wire is positive and the red wire is negative.

Isn't red-positive/black-negative pretty universal?

Had me stumped for an hour or so. F&#kers...



Light bar switch looks a little out of place...

Weird. I have the same one and red is positive.
