5th Gen Wheel & Tire Thread

[MikeDeuce]

Hey folks, some of the other gens have official threads like this, can we please get one started here? I'd like to try out the following format if you would oblige me with the following information:

- Wheel make, model, size, backspacing/offset (+ spacers, if applicable)
- Tire make, model, size
- Suspension (if applicable)
- Photo(s)
- Body mount chop (if applicable)
- Do your tires rub?


Example (I have OE wheels/tires so I'll spare you):

Wheels: Procomp 7069 17x9 4.75 backspace/-6mm offset
Tires: Goodyear Duratrac 285/70/17, D
Suspension: ICON Stage 5, but with their tubular UCA and no trailing arms yet.
Body Mount Chop: None
Tire rub: Haven't wheeled it with this setup yet, but on the street I've only heard it rub once, but I was turning and braking spiritedly and simultaneously.
Fenders: Trimmed about 1/2" on that bottom front lip
Mud flaps: Removed fronts for now, they were rubbing



[Racervx%$]

Ahh this is right on time. Looking now for new rims for my 2013 sr5..



[stoked51]

opcorn:



[Ol'Baditude]

- Wheel make, model, size, backspacing/offset: Konig Countersteer Type X 8", 4.1" BS, -10mm offset
- Tire make, model, size: Cooper STT Pro 295-70R17
- Suspension: Specs in Sig.

These shots show the wheels and tires pretty well.




<script async defer src="//platform.instagram.com/en_US/embeds.js"></script>

- Body Mount Chop: Yep
- Tire rub: No. Not under full lock and/or full flex, nadda.
- Fenders: Front fender well lining removed completely, sheet metal chopped back, fender lining replaced with rubber lining and fender flare re-fitted.
- Mud flaps: Removed fronts.



[Renegad44]

Wheels: 20x9 KMC Chrome, No backspacing/offset
Tires: 275/55/20 Goodyear Eagle LS2s
Rotors: Brake Performance Drilled, zinc-plated, rotors.



I don't off-road mine it's mostly for pleasure cruising and vacations. When it's time to hang out in the boonies/hunting/camping/fishing/4wheeling, I hang with my buddy's, with their 4wheelers..



[MikeDeuce]

You guys are awesome, thanks for participating! No sweat on the on-road vs off-road setups, I think both would be extremely helpful here.

I made an edit, adding a line item for any applicable suspension mods, since it's such a critical aspect of wheel/tire fitment. Anyhow, keep 'em coming folks, your help is much appreciated.



[Antman]

I'll Play!

*17" Level-8 Guardians in satin black- no center caps (Not sure about the offset)

*LT265/70R17 Goodyear Duratracs- Load E

*Bilstein 5100's all the way around- front at 2.5" / Rear SAW 1.5" Coils

*Airlift 1000 rear airbags



Two Pics because it just looks better when it's really dirty!



[adio3x]

I guess I'll play!

-17x9 0 offset Konig Six Shooters Gunmetal (no center caps)

-Spidertrax 1.25 spacers

-295/70/17 Nitto Trail Grapplers

-Front: Toytec Ultimate w/Icon Uniball UCA's, Rear:Bilstein 5160s w/OME 896 springs



[2011YOTA]

Vehicle: 2011 LE
Wheels: Konig Countersteer Type X 17x8 Matte Bronze
Backspacing: 4.1"
Offset: -10mm
Tires: Cooper Discoverer AT3 P265/70/17 (wish I had gone bigger, may be selling these tires soon)
Suspension: Stock (for now)



[Alex T4R]

Here is my two setup I had and have.
Previous
20" Ultra Gauntlets Black
275/55/20 Nitto Terra Grappler on stock suspension

Current:
18" Ultra Gauntlets Black
295/65/18 DuraTrac with 2.5" Icon Coilover and Metal Tech long travel suspension in the rear



[1engineer]

Vehicle: 2012 4Runner TE KDSS/NAV
No Lift
Wheels: Stock TE Rims
Tires: P265/70/17 Cooper Discoverer AT3
All Terrain Tire Review Thread: http://www.toyota-4runner.org/5th-gen-t4rs/114342-tires.html
Tires and Ground Pressure Thread: http://www.toyota-4runner.org/5th-gen-t4rs/138094-5th-gen-4runner-tires-ground-pressure.html



[DannyLlama]

Wheels - KMC Skitch
Size: 18" x 8 Offset: 15mm, 35mm
Tires - Cooper AT3 275/65/18

Will update with some better pics soon, for now:

Before the TE conversion



[DannyLlama]

If I may make a suggestion.
We should put some general wheel, offset/back spacing information on here.
Those questions come up a lot and I myself had posted plenty about this topic in the past looking for info. Including fitment issues and tire size topics.

Thoughts?!



[ImOnAPlain51]

Wheels: Stock SR5
Tires: Goodyear Duratrac 285 70R17
Suspension: Icon Extended travel w/ LR UCAs



[2011T4RLE]

Wheels: Fuel Boost 18x9 -12
Tires: Fuel Mud Terrain 33x12.5x18
Suspenion: OEM with Readylift SST



[FatTiresRollin]

oooh, me too...

I don't want to miss out on the opportunity to post more pics! and see everyone else's of course...

Wheels: Level 8 MK6, 17x8, 0mm Offset
Tires: 285/70/17 Goodyear Duratracs
Suspension: Bilstein 5100 @ 2.5" & Superflex Rear Coils w/ LR UCAs



[adam2562]

- KMC XD Addict, 17x9 -12 offset 4.5" backspace and 106.25 center bore
- 285/70/17 Goodyear Duratrac D load
- 2.5" toytec spacer front and 2" toytec superflex spring rear
- Minor rub..(too little to mess with unless i'm messing with it) i did the fender liner mod and i had no rubbing with the oem wheels and 285's



[Stoff96367]

Wheels: KMC Hoss XD795 20x9 4.5 backspace/-12mm offset
Tires: Nitto Terra Grapplers 285/50R20
Suspension: Pro Comp 2.25" Front, Truxxx 1.25" Rear
Before Lift



[jangoforhire]

I think the first person to post Konig Countersteer Type X's with 285 GY Duratracs will instantly cover 90% of the 5th gen section...



[Cincyvol]

4th Gen LE 18" wheels with 265 65 18 Michelin MS2's.
