Ongoing Review of Revo 2 LT Load E

JB.

New member
The original Performance Zone, 5 page thread that introduced Revo 2 is apparently gone.

In that thread, I went from skeptic to happy owner and ended up putting up enough about my Revo 2 experience that it could have been an ongoing review thread.

Now it is.

I'm restoring my two after purchase posts from that thread (with some rewording), adding a current post, and I'll likely add relevant info from time to time.

Last edited:
Register to hide this ad
From 11-11-2009

Been driving on a set of LT256/70/17 Load Es for a couple of weeks now (no dirt yet). They replaced BFG AT KO same size, load C with 55k on them. (See <a href=http://www.toyota-4runner.org/showthread.php?threadid=40803target="_blank">this</a> thread for info about air pressure for LTs).

As I'd hoped, my pull to the right was gone. (woo hoo!) For some time I had a pull that would remain even after rotation (front/back - new tires will be X rotated). Tracks perfectly straight now which is amazing considering how much time has been spent off-road without ever having it aligned. I'll be keeping an eye on wear, though. I've needed tires for quite a while but couldn't decide between Ps and LTs due to foggy visibility of future use. I came very close to getting Nitto Terra Grapplers in P-metric as the price was very good and, absent substantial off-roading, a much better choice than LT. Their email customer support leaves a lot to be desired, however, so I was glad to go elsewhere. When I emailed an inquiry about tire weight the reply was "it's in the specs", which seemed a bit rude, but even worse considering the Terra Grappler web page doesn't contain the info. (Unfortunately, Tire Racks listed weights sometimes conflict with the weights reported by tire companies). My follow-up email was ignored. Bye, bye, Nitto.

How about more KOs? Another set was not off the table. They served well, surviving a lot of off-road abuse without ever flatting. They look great, but application has to take priority. The tread chunked quite a bit which I mostly forgive, considering the life they led and the Q speed rating, but, having come to view chunking a little less benignly than before, that helped push me in another direction. Even if my tire use ends up justifying the purchase of more LTs, the usage is not likely to match the what the KOs saw so I didn't need a tire quite that aggressive, and I had a specific construction requirement the KOs didn't satisfy. Basically, I wanted an LT A/T that retained much of the KOs off-road characteristics but provided more high speed peace of mind on hot desert highways.

Why Revo 2? My number one requirement was for a tire with full width, circumferential nylon reinforcement of the steel belts, known variously as a nylon cap, nylon cap ply or overlay, or nylon safety belt (usually nylon). A construction traditionally found on H and higher speed rated tires, it's increasingly finding its way into lower speed rated tires to increase safety margin by sharply reducing the possibility of outer belt/tread separation (throwing the tread) which is especially important, imo, in a Light Truck tire and even more important in an LT that gets used hard and sees a lot of hot weather freeway use. The expansion of the use of this construction is apparently another trend accelerated by Ford/Firestone. Several LT ATs I looked at had this, but were eliminated for various reasons. The Revo 2 stuck out for its apparent combination of good performance both on and off pavement. I already had evidence it was quiet (now verified) but it also seemed to have one of the more aggressive tread patterns due to the wide shoulder block voids which are a bit wider on the LT version of the tire. It has an S speed rating which is higher than average for this type of tire (and possibly on the conservative side with the cap ply). This is important to me for both daily and emergency handling, maintaining plenty of reserve against any deterioration in speed capability, and offsetting any uncertainties about running a tire so far away from max design pressure.

So handling is crisper than with the BFGs, that's been fun. Weight is about the same, ˜ 47lbs, so unsprung weight hasn't increased. The tire is light for a Load E so, while having more tensile strength in the sidewall compared to the BFG Load C, it doesn't seem to have additional rubber which is fine with me. I'm happy to have the tire well under 50lbs. I originally preferred Load C but only Load E was available in this size, which was a concern considering what one frequently hears about "stiff" sidewalls and harsh rides. It was either find a different tire or find out for myself. I wasn't real keen on just jumping into a $1K experiment, however. Eventually, extensive research convinced me it wouldn't be a problem and that the stiff sidewall, harsh ride mantra is somewhat of a myth. Compared to air pressure, tire construction is a bit-player when it comes to ride harshness so, at least on that specific issue, once the jump into LT territory has been made, the effect of load range is pretty small. Still, common "knowledge" is not always easy to ignore, so making the purchase was a bit of a leap of faith considering that the cap ply, too, was likely to make a small contribution to a firmer ride. I'm pleased to report that they feel fine at 38psi and I won't hesitate to increase pressure when conditions warrant.

On my recommendation, a friend got a set of Ps (why pass up a free guinea pig ), for his XUV a few weeks prior and took a trip that included a long gravel road drive. I noticed afterwards his tires had picked up a lot of raisin size rocks. It seemed like more than I would have expected. This gave me one more thing to ponder and delayed my purchase a bit, but I decided to ignore it. I'd be curious to hear about this aspect from other owners. If I have to pick out a lot of rocks out after going off-pavement I can live with that considering how much I like the tire overall.

Revo2andBFGinstore.jpg~original


Revo2t4rMedium.jpg~original

Last edited:
From 02-16-2010

The tires have now seen a lot of snow, mud (unfortunately), wet rocks, etc. I'm extremely pleased. They seem better in the snow than I remember the KOs being but that's probably not a valid comparison for a variety of reasons, not the least of which is that the tires are new and benefit from maximum tread depth and rubber pliability. They seem almost immune to hydroplaning but that should come as no surprise with half an inch of new tread and two nice big rain grooves. What did surprise me was the ability of the outer lug voids to shed mud. The rain groove seems to aid the process. I'm not sure it's necessarily true that the tires are less aggressive than the original Revo in any significant way. The opened up voids on the outer lugs work well and seem to go a long way in offsetting the change to a tighter inner tread. No one is going to mistake these for mud terrains but for an A/T that is this good on pavement, it was a pleasant surprise.

Not the greatest example, but here they are packed with mud, and still the shoulder lugs are providing a little grip. You can see the mud starting to pull away at the rain groove.
Revo2sinmud5.jpg~original


This pic was taken seconds later after a few low speed wheel revolutions.
Revo2sinmud6.jpg~original


Revo2sinmud2.jpg~original


The tires have an artistic side.
Revo2tireart.jpg~original

Last edited:
Some old and new info

The original observation about stone retention seems confirmed after noting the results of rock-picking after multiple, long off-pavement exposures. Leatherman indicates truck orientation. If nothing else, it's an interesting illustration of distribution between fronts and rears. Rear tires are reputed to be more prone to flats off-pavement than fronts and this makes it easy to see one of the reasons why this may be the case (though I don't worry much about flats anymore, having experienced none in many thousands of miles off pavement. My tire deflators will have to be pulled from my cold, dead hands). These are worst case scenarios as each is the result of dirt and gravel exposure in the general range of about 100 miles except for the last pic which was the result of more than double that mileage and, surprise, also more than double the number of rocks. However, I usually pick the rocks out only during tire rotation but picked the last batch out right after the dirt exposure, so that may have played a role in the increase.

No complaints, though. Small price to pay for a tire that otherwise fits my usage perfectly. The stone retention shouldn't be an issue for most people, but if someone is going to be putting a lot of off-pavement miles on this tire, it might be worth noting.

----------

(2-23-2014 - Stone retention dropped quite a bit shortly after this. See post #35)

----------


The tracking, handling, balance, wear pattern, and on and off-road traction have all been great. I'm getting no accelerated shoulder wear like I did with the KOs. They're typically used at about 18psi off-road but have been down to 12psi, so the bead fit seems to be fine. Looking at the difference of the treads of the two tires, it shouldn't be a stretch to project that mpg would be significantly better and that has been my firm impression.

In the initial post, I mentioned foggy visibility of tire use. It has turned out that the tires have had a lot asked of them, off pavement, but I've not missed the KOs once. Not claiming equal traction for the Revos, but any difference doesn't call attention to itself. If only on the basis of the wider tread face, the KOs might resist flats a little better, on paper, but the Revos have more than passed acid testing. When back on pavement, I'm reminded what a wide range of performance the tire delivers.

Starting out at 15.5/32nds, tread is now 12/32nds after 23k miles using a 5 tire rotation. Kind of early for precision, but it looks like I should get 65 or 70k out of them going to 5/32nds. I'd be happy with that.


4runtirerocks1.jpg~original


4runtirerocks2.jpg~original


4runtirerocks3.jpg~original


4runtirerocks4.jpg~original

Last edited:
Time for an update.

I finally had a tire rotation cycle that didn't involve an off-pavement trip. I was curious what the stone retention would look like. Not too bad.

Revo2paverocks.jpg~original


-----

Lots more off-pavement travel, with more snow than usual. Very happy, no complaints, though I expect I'd be saying that about many A/Ts.

2011snow.jpg~original


-----

It's interesting to see the difference in tread condition at similar mileages between the BFGs and the Revos (22k and 27k). It's not completely fair as the BFGs had a rougher life to that point, despite having fewer miles, but it's representative, if exaggerated, of the differences I would expect to see between a snowflake A/T with a Q-speed rating, and an S-rated A/T after a couple of desert southwest summers. From the appearance, I'd guess the initial BFG snow advantage had decreased, perhaps even disappeared, due to the tread blocks rounding and chunking, and possibly even the effect of slightly harder tread rubber from higher running temperatures. (BFG later made a change to the tire and assigned it an R speed rating.) The pressures run in both were virtually the same. As can be seen, the Revos are wearing evenly and well.

RevoBFGCustom.jpg~original


BFG22Medium.jpg~original


-----

Since the last post, Consumer Reports has published a large tire issue which includes the category "All Terrain Truck" where they rank 13 tires. The word truck is not a reference to the distinct tire type "Light Truck" (LT). All the tires are P-metric. The report has ten ranked categories: 1.Dry braking, 2.Wet braking, 3.Handling 4.Hydroplaning 5.Snow traction, 6.Ice braking 7.Comfort, 8.Noise, 9.Rolling resistance, 10.Tread life.

Revo 2 scored on the high side of mid-pack. Most of the tires probably come in an LT version, too, and I'm assuming a reasonably consistent carry-over from P to LT in relative performance that would result in the LT versions being arranged similarly in a separate set of rankings, though the Ps, as a group would be expected to outperform the LTs on pavement. Anyway, CR says that they assign a weight to the traction categories higher than the others but I don't really see it in the rankings. If I re-arrange, based only on traction, the rankings change, but the Revos end up about the same anyway.

One of the most noticeable things in the rankings is how much similarity there is among tires, at least when ranked with the resolution of a 5 point scale. It would be nice if CR provided access to the raw measurements but I won't complain too much. Who else compares brands in all tire categories with detailed measurements and then publishes the results? Without that, about all that's left to rely on are surveys (and anecdotes) with all the well known flaws. (Flawed because they're not predictive of how a tire will perform under controlled testing.)

Traction categories had the least variation. The most extreme examples are Wet Traction and Handling where all tires received the same rank except for one (different tires). Of the traction columns, Snow Traction and Ice Braking had the widest variation -- three ranks wide -- ranging from excellent to good, and good to poor, respectively. Not too surprising. The typical A/T tread pattern makes even the worst pretty good in the snow, but if you want great performance on the really slick stuff, go for the dedicated winter tires. The category with the largest variation is tread wear, but if price and tread wear were combined into miles per dollar, the category would be much more uniform. The most noticeable difference, overall, is price. One might guess that smaller tire companies are more enthusiastic about CRs tests than larger ones.

Not surprisingly, Revo 2 was unsurpassed in low noise but I was surprised to see it out ranked by three others in rolling resistance. I'm almost pleased to see it, though, since improved rolling resistance was the basis for my original skepticism mentioned in the first post. I don't want any traction properties to be compromised in pursuit of improved rolling resistance, and the magic triangle of tire design makes that a concern. The triangle is traction (esp. wet), rolling resistance, and tread wear. An improvement in one sacrifices one or both of the others or sacrifices an improvement that could have been made.

Revos were ranked "excellent" (highest rank) in dry braking which works for me since I live in the desert. The snow traction rating of "very good" was one notch lower but I'm happy with that. I don't doubt the BFGs would have scored higher when new on snow and ice (at the cost of dry performance), but I'm not convinced the slight snow advantage of a tire like that is long lasting, especially in a hot climate, where eventually the effects of heat and accelerated wear may end up erasing most of the difference and possibly even result in a crossing of curves with an AT that runs cooler yet has a good snow design. LT/ATs are exempt from UTQG ratings but the speed rating is a good indicator of how hot the tire will run.

If I were buying today, the test results would have me seriously looking at a set of Kuhmo KL78s, which scored highest when I re-arranged for traction, and were nearly the least expensive tire. I'm very happy with the Revos, but I think it would be nuts to ignore the CR test results, especially where a little more performance can be had for less money.

Problem with the Kuhmos (for me) though, is that in 265/70/17 the Load E weighs 54lbs -- compared to 47 for Revo -- and the Load C is Q speed rated (which almost certainly means no cap ply). Both are deal breakers for me, the latter in particular. Load D is not offered. P-metric is a possibility, as I still can't shake the desire to find out for myself how well they can hold up off-pavement.

So with all that, there's a good chance I'd go for Revo 2 again in LT265/70/17 Load E, especially if I could negotiate another good price. The specific weight and performance characteristics appeal to me, and the shoulder lug tread voids, which clear well for an A/T, appear to be wider than the others in the group which might provide a little boost in mud and deeper snow. It seems plausible that if mud and deep snow categories were part of the CR review, Revo 2 might move up. Given the small differences in traction scores anyway, these other factors, along with price, stand out as important differentiators. I could easily see myself with another set as things stand right now.

Last edited:
Awesome Review!

Thanks for the incredible review and comparison with the BFGs. I have been going back and forth for a month on spending the extra $ for the BFG. I was having a nail removed from my wife's tire at Firestone last week and the tire guy recommended the Revo 2. I read a lot of reviews on them and felt pretty safe about buying them over the BFGs especially since I'm on-road 99% of the time. I was also able to negotiate such a sweet deal on the Revo 2s that i couldn't pass it up and am having them installed this weekend. Your post has confirmed my decision and put me at ease worrying about buyers remore.

The pics made a big difference as well and your ride looks sweet with the Revo 2s. I bought my black '03 Limited V8 about a year ago and this is my first first change from stock on this vehicle. I'll have to post some pics once I've got the new rubber on. Thanks again!!

I run off road in the desert a lot and my BFG also chunk but any tire would under the harsh conditions. That seems to happen most at higher speed on rocky trails. That being said I will will replace my BFG all terrains (265/70/17 load range c) with the same. I have recommended them to many people I off road with and we never had a failure in the desert. We beat the crap out of these tires. I will not even go out anymore with someone with stock tires. The high speed long stretches seem to be the biggest problem with stock tires. The sidewall can not take the beating. Are the Revos 3 ply sidewall? They may be fine but I am sticking with what I know works for me.

Thanks for the incredible review and comparison with the BFGs. I have been going back and forth for a month on spending the extra $ for the BFG. I was having a nail removed from my wife's tire at Firestone last week and the tire guy recommended the Revo 2. I read a lot of reviews on them and felt pretty safe about buying them over the BFGs especially since I'm on-road 99% of the time. I was also able to negotiate such a sweet deal on the Revo 2s that i couldn't pass it up and am having them installed this weekend. Your post has confirmed my decision and put me at ease worrying about buyers remore.

The pics made a big difference as well and your ride looks sweet with the Revo 2s. I bought my black '03 Limited V8 about a year ago and this is my first first change from stock on this vehicle. I'll have to post some pics once I've got the new rubber on. Thanks again!!

Glad you found some value in the review. That much detail is not most people's cup of tea.

Are the Revos 3 ply sidewall? They may be fine but I am sticking with what I know works for me.

Don't blame you for not wanting to switch when beating on the tires that hard. The BFGs served me well, too, but I had reasons for wanting to switch that can be read above. Honestly, airing down seems to be such a huge part of the equation, I don't think much about flats anymore. Always prepared, though.

Revo is 2-ply, but what really matters is total ply strength, regardless of number of plies. I fully acknowledge the BFGs toughness, but I'm not convinced 3 plies instead of 2 makes much difference. The tensile strength of the ply (the load range - the air holding strength) is determined by total cord strength, whether it's in 1 ply or 10. Beyond the total cord strength of the sidewall, the resistance to cuts or penetration is mostly a matter of the thickness of the rubber. If, hypothetically, the Revo 2 was found to be less tough in that regard, I would expect it to be simply because the rubber wasn't as thick, not because it had 2 plies instead of 3. Since my Revo 2s are Load E, the two plies, by definition, have more tensile strength than the 3 plies in a BFG Load C. Obviously, that's going to help some in the penetration resistance, but maybe not as much as a bunch of extra rubber. Since it's possible there is less rubber in the Revo 2 Load E sidewall than the BFG Load C, the BFG sidewall still has the potential to be tougher in some respects, but I'm guessing it's close to a wash.

I'd love to get a mechanical engineer's input on this.

Here are some sidewall piece cross section scans of my BFG Load C. The first one is high up on the sidewall. You can see the 3 layers of cords. Lower on the sidewall, where the turnup plies are, there are 6 layers (pic 2) that incrementally reduce down to 3 by the time they reach up high on the sidewall, about where the tire bulges when aired down. A 2-ply Load C would be 2 layers of cord, either thicker or more densely packed, in order to equal the total ply strength of the 3-ply Load C. The Revo, being Load E, would have even more cord material, but it's unknown how thick the rubber is and how far the turnup plies extend up the sidewall. When I'm done with the them, I plan on scanning a piece of sidewall for comparison. Revo 2 is a light Load E so I don't expect more rubber, possibly less.

BFGtiresidewallcutout1.jpg~original

BFGtiresidewallcutout.jpg~original

BFGtiresidewallcutout2.jpg~original

BFGtiresidewallcutout3.jpg~original

Last edited:
You are really getting into your tires. It is cool to see the cutaway of the BFG tire. I would agree that for people who off road only occasionally that the Revo is a fine tire. I do air down off road mainly to make the ride much smoother.

No, the tire is long gone and I was only using a knife, so I wasn't getting past the steel belts.

Just to top this off a bit regarding the Revo II's (LT)...


I commute about 90 miles a day, a pretty windy, 2 lane highway through 3 counties. It ranges form raining in the lower elevations to icing and snowing in the higher. The average speed is probably 60 mph...going as high as 75mph once it opens up getting closer to NYC.

I have to say I'm on my third set, all E range, (first was on a Nissan Titan) and two sets on the 4runner (2010 TE). I do tow several times a year, my farthest trip being Virginia last year. My camper weighs about 2500#'s with the water loaded...and truck carries everything else the camper won't. I put the same tire on the camper as well.

I know how bad the stockies were, and that always goes without saying, but from a traction standpoint, both on road and off road, I can't say enough good things about this tire. We went to off road training last year in Connecticut, and I was the only truck that made it up a few slopes that the others trucks couldn't (and the tires had 35,000 miles on them at that point). I took it off road in Vermont and it was the same thing, but in fairness to the other trucks that had trouble traversing the terrain, I had put on a brand new set just prior to the trip. Many had large lug tires and struggled through some of the muddier sections. I went slow in low range, used my ATrac and locker, and don't think I spun one tire.

I think this a great tire, especially for someone looking for the edge on the pavement, as well as the few times it gets off road. I'll try to post a picture of my tires that were replaced at 45,000 miles...I bet they would have easily made 60,000.

Thanks for the interesting input.

I'm pleased with the tire, too. It really hits the sweet spot for my usage, and I have yet another reason to be pleased with it -- tread life.

Using 5 tires, I'm at 50k and have a very solid 9.5/32nds of tread left. Starting, officially, from 15/32 (I measured 15.5) it appears I could easily get 100,000+ miles out of the set if I wanted to. Even replacing at 5/32 as I intend, should still get me some very long life.

Last edited:
Thanks for the review on the Revo 2

I have been needing to get tires for a while and have been leaning towards the Revo 2, thanks for putting me over the hump.

Got my Revo 2s in LT stock size back in April and I love them. I played around with psi and also found that 38psi is comfortable for city driving although I do go up to 48 on a long highway trip.
I read this thread multiple times while researching tires; thanks [MENTION=2798]JB.[/MENTION] Lots of good info, especially concerning how low you've been able to go when airing down.
I do have a question though:
[MENTION=2798]JB.[/MENTION] Mentions a 5 tire rotation. Does the revo fit under the truck? I only bought 4 initially but I want to get a 5th because if I'm in terrain harsh enough to shred one of these tires, I don't think my P rated spare would get me very far.
What about you [MENTION=47340]Titanpat57[/MENTION]; do you carry one under your 5th gen?

Thanks guys

[MENTION=90685]kowski49[/MENTION]

I dont carry a spare..just a patch kit and small compressor. When I wheel (which to date has included camping) there is a spare under the trailer. The trailer has the same the tires and rims as the truck. I also always bring the Puma 12v compressor, that has about three times the wallop as my MV-50...

Now for the latest dilemma...

I'm going to switch over to Revo 285's this spring. Honestly, I wheeled up in New Hampshire for 5 days after the Cove, and conditions were MUD-DY! I never got stuck, and I have about 28,000+/- on these tires. I did air down to about 18 psi.

So now the problem...the trailer LT's only have about 3-4000 on them. The Revo size is not a huge difference between the 265- 285 size.....so I hope that in a pinch I could use a spare wheel off the trailer, and put the original truck spare(under the trailer) on the trailer until I get it fixed. Or... do I peel the 265 Revo's off the trailer...outfit the spare with an LT Revo (instead of a bullshat stock tire) and just bite the bullet and put 285 LT's on the whole shootin match....

Decisions, decisions....



























This looks like a job for Vodka!!!:flame:

Last edited:
